The Core SWX Hypercore NEO 9 Mini 98Wh AB-Mount Battery is a compact 14.8V, 98Wh lithium-ion battery that supports a constant 12A draw and peak draw of 16A. With this high output, the battery is designed for cine and broadcast applications; but, of course, it can be used for virtually all other applications as well. At only 4.7" in height and weighing just 1.4 lb, it's also highly suited for gimbal, drone, and other mobile applications. The Hypercore NEO 9 Mini has the ergonomic design, large backlit LCD, and protective over-molded rubberized housing that Hypercore batteries have come to be known for over their past releases, but this NEO 9 Mini version is a lot more advanced.

Further leveraging the microprocessor, the NEO packs have an RFID transmitter on the front of the packs, so you can easily grab all your battery data stored from the pack on your phone via our VoltBridgeID app available in the app store.

Not only was the NEO line constructed similar to Helix with the new LCD and RFID, it was also constructed in a modular design like Helix, which reduces cabling and maximises product integrity.  The pack is put together like building blocks within a very small battery housing, reducing the chance of a failure due to a drop or multiple drops. The modular design also makes it very easy to service as the components are plug and play.

Knowing 10A load delivery doesn’t cut it anymore; the NEO packs have an upgraded cell architecture which can sustain up to 16A peak loads, 12A continuous.  In addition, there is SmartTap on the pack allowing you to power any 12vdc device from the p-tap port while also being able to transmit battery data if the device you are using is able to communicate that information.  There is also a 5v USB for charging mobile devices, but also offers additional functionality as a fully function firmware upgrade port, so you will never be left behind as we continue to develop.

Lastly, as with all of our battery packs, they are the most charger compatible on the market. The v-mount offerings will charge on RED, IDX, Sony, etc., and the gold mount offerings will charge on Anton/Bauer chargers.
