RED V-RAPTOR 8K S35 Production Pack (including batteries) (V-Lock)
Capture beautiful Super35 images in resolutions up to 8K120 using the V-RAPTOR 8K S35 DSMC3 camera and a robust complement of accessories with the V-mount V-RAPTOR 8K S35 Production Pack from RED DIGITAL CINEMA. This bundle includes the 8K S35-format camera, four REDVOLT MICRO-V 98Wh V-mount batteries, a dual-battery charger, two 2TB PRO CFexpress cards and one card reader, a RED Touch 7 Inch LCD monitor, a tactical top plate with a V-mount battery adapter, a top handle with extensions, an expander blade, a quick release platform pack, a 5-pin to dual-XLR adapter, side ribs and production plates, and an AC power supply for the camera. Read more below about the components in this pack.
As well as 8K recording, the V-RAPTOR 8K S35 also offers 5K and 4K recording with over-sampling, which gives improved sharpness, colour, and low-light performance. It's capable of frame rates from 24fps to 60fps in 8K, up to 120 fps in 5K, and up to 240 fps in 4K. Other features include built-in wireless control, RED Mini-mag and RED CFast 2.0 recording media, and genlock connectivity. An additional V-Lock battery mount option adds convenience, allowing you to switch between various types of batteries quickly and easily, giving you more power when you need it.
The V-RAPTOR 8K S35's active RF lens mount enables you to adapt your capture for each project using a wide array of pro cine or still photo lenses and can be used with an EF lens adapter. Phase-detect and contrast autofocus is available when used with compatible lenses. This combination of Super35 capture, lens versatility, autofocus (for select lenses), and the compact DSMC3 form enables the V-RAPTOR 8K S35 to fit seamlessly into your wildlife and broadcast projects or other shoots involving lots of handheld work and company moves to multiple locations.
- The V-RAPTOR 8K S35's Super35mm 35.4 MP CMOS sensor provides a practical alternative to full-frame capture that is particularly suitable for in-the-field productions while still offering the high resolution and shallow depth of field beloved by cine-style shooters.
- 16.5+ stops of dynamic range give the V-RAPTOR 8K S35 the ability to capture stunning images in any environment you explore
- A wide range of resolutions and frame rates enables the V-RAPTOR 8K S35 to capture up to 120 fps in 8K, 240 fps in UHD 4k, and 480 fps in 2K, with anamorphic options available in 6K, 7K, and 8K.
- The 8K resolution provides the ability to crop multiple shots in a lower resolution from a single 8K take.
- Super35 lens choices provide a more compact form while offering a wide range of zoom and prime lenses for both broadcast and cine-style productions.
- The locking Canon RF lens mount supports select RF to Canon EF-mount adapters, further expanding your lens selection.
- Phase-detect and contrast autofocus is available with compatible lenses.
- Conveniently located on the assistant's side, an easy-to-navigate, 2.4" LCD panel provides comprehensive control, including status updates, in-camera format selection, and customizable buttons.
- The V-RAPTOR 8K S35's compact and durable DSMC3 form features micro-V battery compatibility, several monitor options, CFexpress card capture, and a modular design that, when paired with a compact Super35 lens, creates a portable, ergonomic form.
- Built-in interfaces include dual 12G/6G/3G-SDI video outputs, genlock, timecode, GPIO, and RS-232 ports.
- Wireless 1080p video preview and camera control are available via dual-band Wi-Fi.
- A 5-pin audio port provides a dual channel mic/line input with +48V phantom power.
Certified for RED V-RAPTOR camera systems, the 2TB PRO CFexpress 2.0 Type B Memory Card from RED offers protection from overheating, operates with a reduced power draw, and helps to ensure high bitrate captures. This card can capture all frame rates and resolutions, including Full HD and raw 4K, 6K, 8K, and 12K video. It features a capacity of 2TB and uses the PCIe 3.0 x2 bus to deliver maximum read/write speeds of 800 MB/s.
The CFexpress Card Reader from RED allows for the fast ingestion of the RED PRO 660GB CFexpress media card on systems that support 20 Gb/s USB 3.2 Gen 2x2. Built with a USB Type-C interface, power is received through the USB bus, meaning that no external power sources are required. The reader features a write-protect switch on the back to protect your data.
Power your KOMODO V-RAPTOR camera with the MICRO-V Battery from RED DIGITAL CINEMA. This 98Wh battery features a compact, lightweight form, up to 12A draw, and data transmission of the remaining time and select accessory information. Designed in conjunction with battery-maker Core SWX, the compact REDVOLT BP is compatible with select other cameras when used with a full-size V-mount adapter.
RED DIGITAL CINEMA Compact Dual Battery Charger (V-Mount)
Charge two V-mount batteries for use with a DSMC3 cinema camera such as the V-RAPTOR 8K VV while on location with the RED Compact Dual V-Mount Battery Charger. Taking advantage of the same technology built into the larger fleet chargers, this compact charger can charge two V-mount REDVOLT MICRO-V or REDVOLT XL-V batteries at a 3A rate. Designed and manufactured in partnership with Core SWX, the charger can charge two REDVOLT MICRO-V 98Wh batteries in less than five hours. A power cable is included.
RED DIGITAL CINEMA DSMC3 RED Touch 7.0" LCD Monitor (Direct Mount)
Add a direct-mount onboard monitor to your DSMC3 camera rig with this DSMC3 RED Touch 7.0" LCD Monitor from RED DIGITAL CINEMA. The RED Touch features daylight viewing, a wide 100% DCI-P3 colour gamut, and touchscreen control for DSMC3 cameras, such as the V-RAPTOR 8K VV. The monitor features a high 322 ppi pixel density, 1920 x 1200 resolution, 1250:1 contrast ratio, and 1300 cd/m² brightness that combine to offer high-quality imaging.
RED DIGITAL CINEMA V-RAPTOR Tactical Top Plate with Battery Adapter (V-Mount)
Use the V-RAPTOR Tactical Top Plate with Battery Adapter from RED DIGITAL CINEMA to securely mount a V-mount battery on your V-RAPTOR BRAIN. Comprised of a top plate, a front cheese plate, and a battery adapter, this snazzy red and black system provides one D-Tap and two 2-pin LEMO ports plus multiple 1/4"-20, 3/8"-16, and M4 accessory mounting threads.
RED DIGITAL CINEMA V-RAPTOR Top Handle with Extensions
The RED DIGITAL CINEMA V-RAPTOR Top Handle with Extensions provides a complete modular top handle solution for the V-RAPTOR, allowing for lightweight or extended wraparound style configurations. It features a dedicated start/stop button, ergonomic bocote wood inlays, and multiple 3/8"-16 and 1/4"-20 mounting points. Additionally, this includes the 1", 3", and 5" top handle extension pieces, an elbow piece and a 15mm Monitor Mount.
RED DIGITAL CINEMA V-RAPTOR Expander Blade
Mount the RED V-RAPTOR Expander Blade to your V-Raptor camera to gain video, power, and communication ports, enabling a wide choice in how you configure your camera for professional applications. The Expander Blade attaches to your camera via the camera's 9-pin EXT port and is supported by the included ARCA plate.
RED DIGITAL CINEMA V-RAPTOR Quick Release Platform Pack
Designed for V-RAPTOR camera users, the RED V-RAPTOR Quick Release Platform Pack is a sturdy yet compact QR plate release system for mounting and balancing your V-Raptor on a tripod. The platform, or baseplate, features 15mm LWS rod clamps and includes two 15mm rods, allowing you to use standard lens supports and accessories such as matte boxes, follow focus units, lens motors, and more with your V-RAPTOR. The platform slides onto the included dovetail plate and has a lever lock to clamp it in place once you have found the balance point you want.
RED DIGITAL CINEMA DSMC3 5-Pin to Dual XLR 3-Pin Adapter
Add two XLR inputs to your V-RAPTOR camera with the RED DSMC3 5-Pin to Dual XLR 3-Pin Adapter. Connect the included 5-pin ODU cable to your camera's ODU port, and the other end of the cable to the adapter's port. The adapter can provide 48V phantom power and supports both mic and line-level inputs. It mounts to the V-Raptor using a 3/8"-26 screw, and has anti-twist pins to prevent it from spinning on your camera. The unit also features 6 x M2.5 screw holes for future accessories.
